Solving Appcelerator Studio’s “Invalid Request” when Compiling

I use Titanium for many of my projects and have found it a great framework. Just like with any tools every once and awhile you run into some interesting errors. I am often switching networks and every once and awhile I get the below error in the Appcelerator Studio console window.

[INFO] :   Alloy compiled in 9.88357s
[INFO] :   Alloy compiler completed successfully
[TRACE] :  offline build file ...
[TRACE] :  online 1
[TRACE] :  sending request ...
[TRACE] :  result from /build-verify=> {"success":false,"error":"invalid request","code":"com.appcelerator.security.invalid.session"}, err=null
[ERROR] :  invalid request

This is an interesting warning as it means the Appcelerator CLI no longer has valid session information.  Great for security, but can be confusing as the error is not resolved by logging in and out of Appcelerator Studio.

This is easily resolved by the following:

  1. Open terminal
  2. Type appc logout, this will logout the Appcelerator CLI
  3. Type appc login, then enter your Appcelerator credentials

If you are using the CLI most likely will never see the above but for those of us that like to use Appcelerator Studio might find this little trick helpful.

Logging Exceptions to Google Analytics Using SwiftyBeaver

There has been an avalanche of Swift based logging frameworks lately.  After trying several, I found SwiftyBeaver was both flexible and simple enough to move all of my apps onto.  Similar to most of the other logging frameworks, SwifyBeaver is extensible. But, unlike many others, there is no real magic injected into the framework making it easy to read and hopefully maintain.  This is best demonstrated by how compacted it’s plugin system is.  You really only need to write you business specific information, the rest is handled for you.

I use Google Analytics for behavior tracking and basic exception tracking today.  Although all of my Google Analytics code is centralized exception reporting is handled explicitly.  With the move to SwiftyBeaver I wanted to see how reporting exceptions to Google Analytics could be handled automatically as part of my logging strategy.  To accomplish this I created the SwiftyBeaver Google Analytics Exception Logger, available here.  Just as the very long name indicates this plugin will automatically post error information to Google Analytics.

Before you start

The Google Analytics Exception plugin requires that you first install SwiftyBeaver and Google Analytics.  You can find information on how to do this below.

After both SwiftyBeaver and Google Analytics have been installed you need to copy the plugin into your project. Instructions for doing this are available here.  You’re now ready to start configuring logging in your project.

Creating your Logger

Creating a logger in your project is extremely simple. Typically you will want to add the below to the top of your AppDelegate.swift so you can use logging throughout your project.

import SwiftyBeaver
let logger = SwiftyBeaver.self

Adding the Google Analytics Logger Destination

Now that you have created your SwiftyBeaver logger you need to add destinations.  Without adding any destinations SwiftyBeaver wont actually do anything.  For this example I’m going to add two destinations. The first will be the built-in Console destination which simply writes to the Xcode console.

let console = ConsoleDestination()
logger.addDestination(console)

Next we’ll add the Google Analytics Exception Logger.  When creating the GABeaver plugin you must added your Google Analytics key.  This will be used when reporting Exceptions.  You can also specify the reporting threshold.  This parameter controls the minimum logging level that should be reported to Google Analytics as an exception. By default this is set to only report error levels or greater.  If you wanted to report warnings or higher you could simply provide a threshold of warning and the plugin will automatically send both warnings and errors.

Below illustrates how to add the Google Analytics Exception plugin with the default settings.

let gaErrorLogger = GABeaver(googleAnalyticsKey: "your GA Key")
logger.addDestination(gaErrorLogger)

Optional Configurations

By default only Error Log messages will be sent to Google Analytics.  You can change this by setting the Threshold property on the logger.

For example, you can record all message with a level of WARNING or great by doing the following:

gaErrorLogger.Threshold = SwiftyBeaver.Level.Warning

You can also configure the logger to write to the console each time a message is logged. To enable console logging, set the printToConsole property to true as shown below:

gaErrorLogger.printToConsole = true

More Information

Additional information is available on github at SwiftyBeaver-GA-Exception-Logger.

SwiftyBeaver

Resetting the iOS Simulator

There seems to be several ways to reset or clear the iOS simulator ranging from pressing the “Reset Content and Settings..” button on the iOS simulator from deleting folder under ~/Library/Developer/CoreSimulator/DerivedData.

For me the easiest and faster approach for my workflow is to simply issue the below in terminal.

xcrun simctl erase all

Review : Xcode 4 Cookbook

Xcode

PACKT recently provided the opportunity for me to review the Xcode 4 Cookbook by Steven Daniel.  As primarily a Titanium developer I spend most of my time in Sublime Text or Titanium Studio so I thought it would provide a good opportunity to spend more time in Xcode.

First, the book title is alittle misleading.  I found this book to be more about iOS development then Xcode itself.  The author does cover Xcode in detail, but always in the context of building or profiling an app.  This approach made it both easier to read and to remember.

The book starts with covering the basics and then moves into creating user interfaces.  Having built most of my UIs through code it I found the content on Interface Builder and Storyboards helpful.  The recipes are easy to follow and very detailed, perfect for beginners.

My favorite section of the book is around instruments.  Again the author walks us through these recipes in a very detailed easy to follow way.  As a side note, you can use the same steps outlined in these recipes in your Titanium project. You just need to generate a full Xcode project using transport.py as detailed here.  Coming from a non Xcode background, the navigation and descriptions of the options available for profiling made Xcode’s sometimes challenging interface easy to understand.

The chapter on iCloud provided a great “getting started” guide with a clear easy to understand recipe showing on to implement Document based storage using NSUbiquitousKeyValueStore.  This was a good introduction to iCloud and very easy for someone new to iCloud to follow along.  I do wish the author would have gone further on this topic and provided more details on storing greater the 64k documents.

The recipe using CoreImage provides a nice introduction to the topic and discusses a few of the common available filters.  This recipe provided a nice transition from the earlier CoreGraphic recipe.  I do wish the author would have provides a multi filter example though.

Overall, I really enjoyed reading this book and found the recipes helpful.  The detail and direction provided by the author makes all of the recipes easy to follow and quick to perform.  If you are new to iOS development or Xcode this book provides the resources needed to tackle that learning curve quickly.

A Few Helpful Xcode Plugins

Xcode is one of those IDEs that you either love or hate ( sometimes both ).  Coming from a Visual Studio background it has taken awhile to get used to the Xcode workflow.  I’m still hopeful that someone will create a Resharper like tool for Xcode, but until then I wanted to share some of the plugins that I’ve found useful.

Completion Dictionary

This plugin provides enhanced auto completion.  I bounce between languages frequently and this makes remembering the specific syntax I’m thinking of much easier.

http://www.obdev.at/products/completion-dictionary/index.html

Code Pilot

Calling this Spotlight for for Xcode would be an understatement.  Once you get used to Code Pilot you will rarely leave the keyboard. In short navigation made easy.

http://codepilot.cc/

Accessorizer

This plugin seems to be the closest thing Xcode has to Resharper.  With 40+ code generation actions and a ton of help this is well worth the small purchase price.

http://www.kevincallahan.org/software/accessorizer.html

Color Sense

This visual plugin provides a color picker when working with UIColor ( and NSColor ).  I rarely use this plugin, but when I do it is a time saver.

https://github.com/omz/Colorsense-for-Xcode

KSImageNamed-Xcode

Can’t remember whether that image you just added to the project was called button-separator-left or button-left-separator? Now you don’t have to, because this will autocomplete your imageNamed: calls like you’d expect. Just type in [NSImage imageNamed: or [UIImage imageNamed: and all the images in your project will conveniently appear in the autocomplete menu.

Read more about this plugin on Kent Sutherlands blog.

On Github: https://github.com/ksuther/KSImageNamed-Xcode

XcodeColors

XcodeColors allows you to use colors in the Xcode debugging console.

https://github.com/robbiehanson/XcodeColors

HOStringSense

If you work with large strings in your code you will definitely want to check out this plugin.  You can enter your full string into this plugin’s UI and it will correctly escape and insert the string into your code.

https://github.com/holtwick/HOStringSense-for-Xcode

Bracket Matcher

This plugin automatically inserting paired message sending brackets. Maybe I’m missing something but shouldn’t Xcode do this for you by default?

https://github.com/ciaran/xcode-bracket-matcher

Fixins

I recently found a github project by Dave Keck that has several Xcode plugins are extremely useful.  My favorite is the CurrentLineHighligher but would recommend checking them all out.

  • CurrentLineHighlighter
  • DisableAnimations
  • FindFix
  • HideDistractions
  • InhibitTabNextPlaceholder
  • TabAcceptsCompletion

https://github.com/davekeck/Xcode-4-Fixins

MiniXCode

Just want to focus on the code? This plugin allows you to reduce the sometimes massive Xcode toolbars.

https://github.com/omz/MiniXcode



AppCode

A commenter (Nick) mentioned that JetBrains has a great IDE called AppCode available at http://www.jetbrains.com/objc.

iOS Simulator Switching Devices

With Apple’s latest products, including the iPhone 5 we now have to worry about more form factors then ever. As the method for switching the device type in Titanium Studio is still pretty clumsy I went in search of an earlier way.

The Appcelerator forums had a great post by Rob Gabbard with an AppleScript helper to do just what I was looking for. With a small update to add support for the Retina iPad and iPhone 5 I can now switch devices must easier.

I wanted to share a link to this script for anyone that might have missed the QA post. Unfortunately this doesn’t address the need for the app to be launched again when the device is changed.

set selectedDevices to choose from list {"iPhone", "iPhone (Retina 3.5-inch)", "iPhone (Retina 4-inch)", "iPad", "iPad (Retina)"} with prompt "Choose device type:" default items {"iPhone"} without multiple selections allowed
if selectedDevices is not false then
    set selectedDevice to item 1 of selectedDevices as string
    set thePListFolderPath to path to preferences folder from user domain as string
    set thePListPath to thePListFolderPath & "com.apple.iphonesimulator.plist"

    tell application "System Events"
        tell property list file thePListPath
            tell contents
                set value of property list item "SimulateDevice" to selectedDevice
            end tell
        end tell
    end tell
end if

View the the gist of the script.
